| Main technical parameters of the product | |||
| Product Name: | CLW9408GFW Type Tank Semi-Trailer for Transporting Corrosive Goods | External dimensions: | 11000X2500X3850(mm) |
| Chassis model: | Cargo box dimensions: | XX (mm) | |
| Total mass: | 40000 (Kg) | Approach/departure angle: | -/20(°) |
| Rated weight: | 33000 (Kg) | Front overhang and rear overhang: | -/1480(mm) |
| Curb weight: | 7000 (Kg) | Maximum speed: | (km/h) |
| Vehicle Notes: | A tractor unit suitable for towing semi-trailers transporting dangerous goods is used. Transport medium: hydrochloric acid. sulfuric acid, nitric acid, Phosphoric acid, hypochlorite solution, Aluminum chloride solution, The density of the medium is 1.1 tons per cubic meter. Category number: 8 Effective tank volume: 31.5 cubic meters. This vehicle is a three-axle gooseneck semi-trailer: Tank dimensions (length × diameter) (mm): The front half of the tank is 3850 × 1950 mm. The rear section measures 6750×2100 mm. Protective material: Q235A carbon steel. Connection method: The left and right sides and the lower rear guard are all connected by welding. Rear guard section dimensions (mm): 140×50 Rear protection ground clearance (mm): 540 ABS manufacturer: Guangzhou Kemi Automotive Braking Technology Development Co., Ltd. ABS model: CM2XL-4S/2K (4S/2M). Mudguard style optional. |
||
| Chassis parameters | |||
| Chassis model: | Fuel type: | ||
| Number of axes: | 3 | Front track: | (mm) |
| Wheelbase: | 5640+1310+1310 | Rear track: | 1840/1840/1840(mm) |
| Number of passengers in the driver's cab: | Number of leaf springs: | -/8/8/8,-/4/4/4 | |
| Number of tires: | 12 | Axle load: | -/24000 (three-axis group) |
| Tire specifications: | 11.00R20
12PR 12R22.5 12PR |
||
| Emission standards: | |||
