| Main technical parameters of the product | |||
| Product Name: | CLW9409GFWB Type Tank Semi-Trailer for Transporting Corrosive Goods | External dimensions: | 9900X2500X3650(mm) |
| Chassis model: | Cargo box dimensions: | XX (mm) | |
| Total mass: | 40000 (Kg) | Approach/departure angle: | -/19(°) |
| Rated weight: | 33000 (Kg) | Front overhang and rear overhang: | -/1450(mm) |
| Curb weight: | 7000 (Kg) | Maximum speed: | (km/h) |
| Vehicle Notes: | A tractor unit suitable for towing semi-trailers carrying hazardous materials is used. Different styles of mudguards are available as options. Optional toolbox location. Transportation category item number: 8. Effective tank volume: 19.9 cubic meters. Tank dimensions (length × diameter) (mm): Front half is 3200 × 1700. The rear section measures 6200x1900 mm. Protective material: Q235A carbon steel. Connection method: The left and right sides and the lower rear guard are all connected by welding. Rear guard section dimensions (mm): 140×50 Rear protection ground clearance (mm): 500. ABS manufacturer/model: Guangzhou Kemi Automotive Braking Technology Development Co., Ltd./CM2XL-4S/2K(4S/2M). Liangshan Shunanda Automotive Technology Co., Ltd. / SAD-ABS4S/2M Liangshan Hainan Electronic Technology Development Co., Ltd. / HNABS-4S/2M. Type of vehicle for transporting dangerous goods (AT type vehicle). |
||
| Chassis parameters | |||
| Chassis model: | Fuel type: | ||
| Number of axes: | 3 | Front track: | -(mm) |
| Wheelbase: | 4600+1310+1310 | Rear track: | 1840/1840/1840(mm) |
| Number of passengers in the driver's cab: | Number of leaf springs: | -/8/8/8,-/4/4/4 | |
| Number of tires: | 12 | Axle load: | -/24000 (three-axis group) |
| Tire specifications: | 11.00R20
12PR 12R22.5 12PR |
||
| Emission standards: | |||
