| Main technical performance parameters of CLW9401TJZG type container semi-trailer: | |||
| Product Name: | CLW9401TJZG type container semi-trailer | External dimensions: | 9550X2490X1510(mm) |
| Chassis model: | Cargo box dimensions: | XX(mm) | |
| Total mass: | 40000 (kg) | Approach/Departure Angle: | -/15 ( ° ) |
| Rated weight: | 35000 (kg) | Front/Rear Suspension: | -/1420 (mm) |
| Curb weight: | 5000 (kg) | Maximum speed: | (km/h) |
| Engine Model | Manufacturer | Power (kW) | Displacement (ml) |
| Emission standards: | |||
| Number of axes: | Front track: | - (mm) | |
| Wheelbase: | 4350+1310+1310 (mm) | Rear track: | 1840/1840/1840 (mm) |
| Rated passenger capacity | (people) | Vehicle Identification Code | LA939VST×××CLW××× |
| Fuel type: | Number of leaf springs: | -/8/8/8 | |
| Axle load: | -/24000 (parallel three-axis mounting) | Number of passengers in the driver's cab | |
| other: | The unloaded ground clearance of the saddle bearing surface of the container semi-trailer tractor is 1310mm, and the total frame height at the towing pin is 85mm. This vehicle is used for transporting 30-foot tank containers or other containers. Protective material: Q235 carbon steel; connection method: welded connections for the left and right sides and lower rear protection; rear protection cross-section dimensions (mm): 120×50×5; rear protection ground clearance (mm): 530. ABS manufacturer: Hander International Trading (Shanghai) Co., Ltd.; ABS model: 4S/3M. | ||
