| Main technical parameters of the product | |||
| Product Name: | CLW9402TJZ type container transport semi-trailer | External dimensions: | 14990X2490X1550(mm) |
| Chassis model: | Cargo box dimensions: | XX (mm) | |
| Total mass: | 40000 (Kg) | Approach/departure angle: | -/12(°) |
| Rated weight: | 34200 (Kg) | Front overhang and rear overhang: | -/2840(mm) |
| Curb weight: | 5800 (Kg) | Maximum speed: | (km/h) |
| Vehicle Notes: | The frame height at the towing pin is 210mm. This vehicle has a small gooseneck structure. It is used to transport 48-foot containers. Protective material: Q235; Connection method: The left and right sides and rear lower protective devices are all welded connections. Rear lower protective device cross-section dimensions (mm): 170×50; Rear lower protective device ground clearance (mm): 540. ABS system controller model: CM2XL-4S/2K (4S/2M); ABS system controller manufacturer: Guangzhou Kemi Automotive Braking Technology Development Co., Ltd. A container semi-trailer tractor is used. | ||
| Chassis parameters | |||
| Chassis model: | Fuel type: | ||
| Number of axes: | 3 | Front track: | -(mm) |
| Wheelbase: | 8240+1310+1310 | Rear track: | 1840/1840/1840(mm) |
| Number of passengers in the driver's cab: | Number of leaf springs: | -/8/8/8,-/10/10/10 | |
| Number of tires: | 12 | Axle load: | -/24000 (parallel three-axis mounting) |
| Tire specifications: | 11.00R20 12PR, 12R22.5 12PR | ||
| Emission standards: | |||
