| Main technical parameters of the product | |||
| Product Name: | CLW9170TCL type vehicle transport semi-trailer | External dimensions: | 14000X2500X4000(mm) |
| Chassis model: | Cargo box dimensions: | XX (mm) | |
| Total mass: | 17495 (Kg) | Approach/departure angle: | -/12(°) |
| Rated weight: | 7000 (Kg) | Front overhang and rear overhang: | -/2650(mm) |
| Curb weight: | 10495 (Kg) | Maximum speed: | (km/h) |
| Vehicle Notes: | This vehicle can be used with tractors such as DFL4160B1, DFL4180A2, CA4163P7K1E, and BJ4181SLFJA-S5. Protective material: Q235 carbon steel; connection method: welded connections for both sides and the lower rear; rear protective section dimensions (mm): 100×50×5; rear protective ground clearance (mm): 400. ABS manufacturer: Jiaozuo Boruike Control Technology Co., Ltd.; ABS model: G ABS. | ||
| Chassis parameters | |||
| Chassis model: | Fuel type: | ||
| Number of axes: | Front track: | -(mm) | |
| Wheelbase: | 8090+1435 | Rear track: | 2160/2160(mm) |
| Number of passengers in the driver's cab: | Number of leaf springs: | -/8/8 | |
| Number of tires: | 4 | Axle load: | -/4620/4620 |
| Tire specifications: | 11.00R20 12PR | ||
| Emission standards: | |||
